neko10082

English： Thank you very much for your help. At present, I live in China. If you ship the graphics card to me, it may cost a high freight, which may cost $50 or more? Probably. However, I'd be happy to try to help you repair them. I now have two m40, one of which is helping me with the game and the other is used for project research. In China, due to mining（ETH）, the price of graphics card is very high, and the 3060ti with the highest cost performance has increased from the recommended retail price of 2499RMB (395USD) to 5699RMB (900USD) Chinese： 非常感谢你的帮助，目前我居住在中国，你把显卡运送给我可能会产生很高的运费，可能需要50美元或者更高？大概。不过，我很乐意尝试帮你去修复它们。我现在有两张M40，其中一张在帮助我进行游戏，另一张则用于项目研究。在中国因为挖矿 ETH的关系，显卡价格非常高，其中性价比最高的3060ti从建议零售价从2499人民币 （395美元）升高到5699RMB（900美元）

English： Haha, I thought this Emoji meant French fries at first, and now I fully understand it. In China, popcorn is also associated with entertainment or watching movies, but our tradition is to eat watermelon and peanuts, so you will see that the expression in my last reply is that a person or a group of people are eating watermelon Chinese： 哈哈 ，我开始以为这个Emoji是薯条的意思，现在我完全明白了。在中国爆米花也与娱乐或者看电影联系起来，不过我们的传统是用吃西瓜以及吃花生米，所以你会看到我上一个回复里面的表情是一个人或者你群人在吃西瓜

Although I can't fully understand what you mean, can I explain it to "吃瓜群众" in Chinese? " "吃瓜群众" meant "give me tea" or "watch the fun" chinese：虽然我不能完全理解你整句话的意思，但我能把它解释为“吃瓜群众“用的中文吗。”吃瓜群众” 意思是“看热闹”

English： Don't say that, you're also great, but everyone's good at something different Chinese： 别这么说，你同样也很棒，只是每个人擅长的东西不一样

English： I tried this method last night. It does change the Device ID information that is recognized by the system. It can cheat the installation of unmodified driver software directly, but the system will not load into M40 correctly after installing the driver, because the registry modified information will be restored after installing the driver, and it will not load into the graphics card correctly when I modify it again. No GPU is also prompted in the nvida control panel. Chinese： 我昨晚对这个方法进行了尝试，这个操作确实会改变系统所识别到的 Device ID 信息，它可以骗过未修改驱动软件直接进行安装，但安装完驱动后系统不会正确加载到M40，因为安装驱动后对注册表修改的信息会还原，当我重新修改后也不会正确加载到显卡，在nvida控制面板中也提示无gpu。

English：Yes, I planned to do that first.but I don't have all the materials yet, but I'm already on the way to buy them.But my Maxwell assembly drawing is not very clear, which also requires me to spend some time on data sorting. Chinese： 是的，我也是先打算这么做，但是我的材料还不齐全，但是已经在采购路上了，但是我的Maxwell 板卡装配图不太清楚，这也需要我花一点时间进行数据整理。

English： Hello, @emci. Yes, I have welded the display interface to the m40, but strangely there is no video output. What I can confirm at the moment is that the power supply between the Hotplug Detection and the interface must be normal, because when I insert the DP interface, the display will prompt the interface to insert, but after two seconds it will prompt for no signal input. I look at the system and do not recognize the display insert. I'll send the parameters of my welding and the suggested identification for you to compare。Tomorrow I'll try to weld the DVI interface as well. I hope everything goes well. Chinese： 你好，@emci 。是的我已经将显示接口焊接到m40上，但奇怪的是没有任何视频输出，目前我能确认的是热插拔检测与接口供电一定是正常的，因为当我插入DP线后，显示器会提示接口插入，但两秒过后提示无信号输入，我在系统中查看，并没有识别到显示器插入。我把我焊接的参数与建议标识发上来 方便您进行比对。明天我试试把dvi接口也进行焊接，希望一切顺利。 _NvidiaGTX980TI(PG600).pdf _NvidiaGTX980TI(PG600)BoardViev.pdf

English： This is my related data file about Maxwell boards. I send it to you for reference. At present, my test and analysis is stagnant. I hope you can provide more ideas or suggestions. Thank you. Chinese： 这是我的关于Maxwell 板卡的相关资料文件，我把他发上来给大家做参考，目前我的测试和分析已经停滞，我希望大家能提供更多的点子或者建议，谢谢大家。 https://ne-ko.cn:15001/fsdownload/jzP0aBmKy/ This is my cloud disk, valid for 30 days

English： Hello, @emci Mr stay safe! I hope you can go home safely. Where are you from? I hope no country will use war and chaos. Chinese ：你好，@emci 先生 注意安全! 希望你能平安回家。你来自哪里？ 希望任何国家都没用战争和混乱。

Oh, this should be bad news for me, the information I got from my Chinese data may be wrong.I need to re-check Maxwell Boards to see if there is any method to modify the Device ID. If the Device ID cannot be modified, I think the success rate of modifying the display output interface is 0. I also have the data you provided. I sent the data I held in the morning, but it is too late now. My local time is 3:30 in the morning have a good day ！ chinese：艹，这对我来说应该是一个坏消息，我从我的中文资料中获得的资料可能是错误的。我需要重新检查Maxwell 板卡是否还有能修改Device ID的方法。如果不能修改Device ID我认为改装显示输出接口的成功率为0。您提供的这一份资料我也有，我在早上把我持有的资料也发上来，现在已经太晚了，我当地的时间是凌晨3：30

Hello, thank you very much for your help. I have successfully installed the driver for the Tesla M40 with m6000 vbios, but I found that the nvida control center and hwinfo detected the Tesla M40 graphics card, which should be the reason for the device ID. I think it's time to start investigating how to change the device ID by changing the resistance unit of the resistor near BIOS in pcb, because before the 10xx series, the resistance unit of the resistor near BIOS was used to change the ID. I need to buy a broken Titan X or m6000 to modify the resistance because I don't have the drawings for both graphics cards. chinese：你好，非常感谢您的帮助。我已经把带有m6000 vbios的tesla m40成功安装好驱动，但是我发现nvida控制中心与hwinfo检测的还是tesla m40显卡，这应该是device ID的原因 。我觉得应该开始研究通过更改pcb中bios附近电阻的resistance unit来改变device id，因为在10xx系列前，是通过bios附近连接的电阻的resistance unit来达到改变id的。我需要购买一张坏掉的titan x或者m6000来对照电阻进行修改，因为我没有这两张显卡的设计图.

This is my modified Tesla M40，using evga's water cooled radiator chinese：这个是我改装的 tesla m40，使用的是evga的水冷散热器

Hi, everyone. I am from China. My English is not good. Please forgive me. I'm trying to weld the display interface to Tesla M40 and modify it to Titan X or m6000, but I find that no matter how my SPI-programmer uses the VBIOS firmware of Titan X or m6000, it doesn't recognize the graphics card properly. When I write a non-m40 VBIOS firmware, the device manager will show that the 3D video controller is malfunctioning and prompt that there is no compatible driver for this device (code 28). GPU-Z doesn't recognize graphics cards, even if I use the same version of VBIOS firmware as @emci chinese：嗨大家好，我来自中国，我的英文不太好，请见谅。我正在尝试给 tesla m40 焊接显示接口并修改成titan x或者m6000，但是我发现 ，无论我编程器使用titan x或m6000的vbios固件都无法正常识别到显卡 ，当我写入的不是m40 vbios固件后设备管理器会显示3D视频控制器出现故障，并提示这个设备没有兼容的驱动程序（代码28），GPU-Z也无法识别到显卡，即使我使用与@emci 先生一样版本的vbios固件
